'Shore a Hardness of a Rubber Cot and ItsRestrictions in Measuring the Hardness Value under Mill Conditions'


Abstract


Shore hardness


Generally Shore hardness of a rubber cot is measured by using an instrumentcalled Durometer and the value is expressed in A scale


Cots are available in wide shore hardness ranging from 63to 90 shore. These ranges are offered to mills based on the followingparameters:


  • Nature of raw material processed
  • Linear density of material.
  • Type of application / process / mechanical conditions
  • Maintenance aspects.
  • Ambient conditions.


A wide spread phenomenon in the industry is that a softercot having 65 shore A should give relatively better quality yarn as comparedto a cot having higher shore A value say,70 shore A. At the same time softcots have their own drawbacks like wear out rate is faster, damage to the cotssurface will be more. If ambient condition in the spinning shed is not wellmaintained, the soft cot will display greater for lapping.


In terms of maintenance aspect, the grinding machineoperator should be highly skilled for achieving good surface characteristics.


Definition of shore hardness


Hardness may be defined as the resistance to indention underconditions that do not puncture the rubber. It is called elastic modulus ofrubber compound. These tests are based on the measurement of the penetration ofthe rigid ball into the rubber test piece under specific conditions. Themeasured penetration is converted into hardness degrees.



Normally spring loaded pocket size Durometer is commonly used for measuring hardness of the elastomers.Shore A Durometer is used for measuring soft solid rubber compounds. Otherscales are also used like Shore D which is used to measure the hardness of veryhard rubber compounds including ebonite. The main drawback is in reproducibility of results by different operators. So, a practical tolerance of 5 is acceptable.


Better reproducibility is obtained by dead weight loading. Here the hardness is expressed in IRHD International Rubber Hardness Degrees. Both IRHD, Durometer tests requires rubber specimen of definite dimensions. As per the ASTM (D 2240- Defines apparatus to be used and its sections such as diameter , length of the indentor , force of spring and D 1415 Defines specimen size), DIN, BRITISH & ISO Standards following test conditions have been laid for measuring SHORE A HARDNESS of rubber products.


1)    The specimen should be at least 6 mm in thickness.

2)    The surface on which the measurement made should be flat.

3)    The lateral dimension of the specimen should be sufficient to permit measurements at least 12 mm from the edges.








Impact of temperature on hardness measurements on various rubbers:


While testing Synthetic rubber cots in finished product state the following factors plays very important role:


1)    Most of the R/F & S/F cots have wall thickness < 6.0 mm.

2)    If the thickness of Core is considered then the thickness of rubber layer goes further.

3)    Surface on which hardness is tested is not Flat its in constant curvature.

4)    Pressure applied will vary in each test.










Results

Effect




The hardness reading on the cots surface has an impact of the cots core hardness which is of metal or harder polymer.

Hardness measured on cot will be generally higher than the designated hardness by 2 3 degree

Softer the cot, higher is the impact of Core hardness as shown in the fig.

With the reduction in diameter of the cots after repeated buffing , the impact of core hardness increases (Please refer the below table )



Impact of reduction in cot diameter on shore A Hardness in different qualities:


S.No

Cot Dia (mm)

65

70

75

83

1

29.00

66

72

76

81

2

28.50

67

73

77

82

3

28.00

68

73

77

83

4

27.50

68

74

78

83

5

27.00

69

75

79

83




About the Author:


The author is the Manager-Application Technology, Inarco Ltd.
